Insulating Glass Assembly Table
Product ID : FGI-MS2016
Product Attributes :
1.It is used for assembly Insulating glass, for install rubber strip or super spacer.
2.Table with vacuum absorption and air floating function
3.Sucker cup can be rotated 360 degree, with lock.
Product Description
Basic Info.
Model NO.
FGI-MS2016
Dimension
2000X1600X870mm
Trademark
FGTECH
Transport Package
Iron Frame & Shrink Film
Specification
Voltage: 3P 380V 50Hz
Origin
China
Function:
1.It is used for assembly Insulating glass, for install rubber strip or super spacer.
2.Table with vacuum absorption and air floating function
3.Sucker cup can be rotated 360 degree, with lock.
Technical Parameter
- Voltage: 3P 380V 50Hz
- Power: 2.2Kw
- Max. Glass size: 2000x1600mm
- Max. Tilting angle: 80degree
- Max. Glass weight: 150Kg
- Air Pressure: 0.4-0.8Mpa
- Dimension: 2000x1600x870mm
- Weight: 500kg
